| item | unit | quantity | notice |
| Overall size | 7600mm length*2490mm width the height will be adjusted according to your matched tractor, detail according to drawing | ||
| axle | piece | 2 | 13 Ton FUWA |
| tyre | piece | 9 | 11R22.5, with one spare tire |
| rim | piece | 9 | 8.25-22.5 |
| leaf spring | sets | 4 | 90width*10pieces*13 thickness |
| braking system | set | 2 line air braking system with air tank ,emergency relay valve,braking chambers and mechanical slack adjusters. | |
electrical system | set | 1 | 24 volt electrical system.7 pin electrical, LED lights, connector.parking .stop,reverse,number plate and indicator lights.rear lights conform to European standard,rear front and side reflectors |
| suspension | set | 2 | CIMC reincorced type, the high quality Q345 steel |
| relay valve | whole vehicle | WABCO | |
| landing gear | pair | 1 | 19inch, one side operation |
| kingpin | piece | 1 | JOST bolted type, 50# KZ1012， |
| tie-in | piece | 2 | haldex |
| twist lock | set | 4 | to load 1*20' container |
| chamber | piece | 4 | double T30/30 4 pcs |
| upper and lower wing plates | 10/12mm,width146mm high tensile steel | ||
main beam | Main beam450mm，webplate:5mm | ||
| reflectors | Red triangle reflectors at the rear of the trailer and | ||
| Shotblasting and paint | Chassis is comletely shor blasted to SA 2.5 grade,and painted with first layer of international Zinc Epoxy primer(30 Microns DEF),second layer international high built polyurethane under coat(40 microns DFT),THIRD AND FORTH LAYERS INTERNATIONAL alkyd FINISH TOP coat.total 80-100 microns. high quality painting | ||
| spare tyre carrier | 1 | standard | |
| color | according to your detail RAL code color | ||
| payment terms | 30% TT in advance,the balance should be paid prior to the delivery |
